Description

Oculux 2″ is an architectural grade recessed downlight with trim, LED light engine, and configurable housing ready to install as an IC-Rated new construction or remodel all-in-one unit. Oculux is Energy Star Rated and CEC Title 24 Compliant with wet location listing which means it can be installed in a broad range of applications. 35 Degree visual cutoff provides superb glare reduction. Available in Round or Square open reflector and adjustable trim options.

• Finish:Brushed Nickel, Haze or White
• Made of Aluminum
• Shade/Glass Color: Frosted Glass Diffuser
• Shade/Glass Made of Glass
• (1) 9W LED Bulb
• Bulb Included
• Bulb Color Temp: 2700/3000
• Bulb Average Hours: 50000
• Bulb Lumens: 650
• Bulb Beam Spread: 25
• Bulb Shape: LED Module
• Voltage: 120
• Dimmable: Yes
• Wire Length: Airtight: Yes”
• Trim, LED light engine, and housing are all included complete. Energy Star Rated and CEC Title 24 Compliant.
• Housing can be configured as an IC-Rated new construction or IC-Rated remodel. Available in Round or Square open reflector and adjustable trim options.
• Oculux is Wet Location Listed which means it can be used in a wide range of applications. 35 Degree visual cutoff provides superb glare reduction.
• Ultimate dimming versatility: Smooth and continuous dimming with an ELV, TRIAC, or 0-10V Dimmer.
• High Powered LED: Color Temperature: 2700K or 3000K, Rated Hours: 50,000, up to 700 Lumens, CRI: 90+, Voltage: 120V Input.
• Standards: ETL & cETL Wet location listed. IC-Rated Airtight Housing. Energy Star and CEC Title 24 Compliant.
• Hardwired
• Part of the Precision Multiples Collection
• Style: Functional
• For Use in Exterior Locations
• Safety Rating: ETL, cETL
• Energy Star: Yes
• Warranty Info: 5 Years Functional, 2 Years Finish

Overall Dimensions: 14.5″(L) x 5.88″(W) x 3.96″(H)

Minimum Height: 14.5″

Maximum Height: 24.5″

Backplate/Canopy Dimensions: Aperture: 2.15″(D) x IC Rating: Yes”(Dia) x Trim Size: 3.54″(W) x Cutout: 3.06″(H)

Item Weight: 3.13 lbs.
